Bowers & Wilkins CDM7 SE

High End Reprosoustavy

Bowers & WilkinsCDM7 SE

Description: 3-way 4th-order vented-box system

Drive units:

1x 165mm (6½ in) Paper/Kevlar®fibre cone bass

1x 165mm (6½in) woven Kevlar®cone bass/midrange

1x 26mm (1in) metal dome high-frequency

Frequency range: -6 dB at 30 Hz and 30 kHz

Frequency response: 40 Hz – 20kHz ± 3 dB on reference axis

Dispersion:

Within 2 dB of response on reference axis

Horizontal: over 40° arc

Vertical: over 10° arc

Sensitivity: 90 dB spl (2.83 V, 1 m)

Harmonic distortion: 2nd & 3rd harmonics < 1% 45 Hz – 20 kHz (90dB spl, 1 m)

Nominal impedance: 8 Ω (minimum 4 Ω)

Crossover frequencies: 150 Hz, 3 kHz

Power handling: 30 W – 150 W continuous into 8 Ω on unclipped programme

Max. recommended cable impedance: 0.2 Ω

Dimensions:

Height: 950 mm (37⅜ in)

Width: 220 mm (8⅝ in)

Depth: 290 mm (11⅜ in)

Net Weight: 18.5 kg (40.7 lb)

Reprosoustavy ve vynikajicim technickem i vizualnim stavu .
